ASME B16.34 Ball Valve, A351 CF8, 2 PC, 1 IN, 1000 PSI, NPT
- Product Name:
- ASME B16.34 Ball Valve, 2 Piece
- Design Standard:
- API 6D, ASME B16.34
- Body Material:
- ASTM A351 CF8
- Size:
- 1 Inch, DN25
- Pressure:
- 1000 PSI
- End Connection:
- NPT Threaded
- Operation:
- Lever
Key Specifications / Features
The ASME B16.34 Ball Valve Factory in China produces high-quality ball valves that adhere to API 6D standards. These valves feature a 2-piece body made from stainless steel ASTM A351 CF8, ensuring durability and corrosion resistance. Available in a size of 1 inch (DN25), they operate at a pressure rating of 1000 PSI. The valves come with NPT (National Pipe Thread) threaded ends for secure connections and are lever-operated for easy control.
We offer two-piece split body ball valves, available in both forged and investment castings. These valves feature a compact structure and tight shut-off sealing. Designed and manufactured to the latest international standards, including API 6D, ASME B16.34, and BS 5351, they come with standard features such as fire-safe design, anti-static, and blow-out prevention. The stainless steel construction makes these ball valves suitable for a wide range of applications, including water, oil, and gas industries.
Product Specifications
» Size: 1/2-4 Inch (DN15-DN100)
» Pressure: 1000 PSI, PN16
» Material: SS 201, SS 304, SS 316, ASTM A216 WCB, A351 CF8, CF8M, CF3, CF3M, etc.
» Sealing: PTFE, RPTFE, PPL, etc.
» Suitable Medium: Water, oil, air, and some corrosive liquids (WOG)
» Temperature Range: -20°C to 250°C
» Connection: F/F threaded
» Type of Thread: NPT, BSPT, BSP, PT
» Thread Standard: DIN 2999
Materials of Main Parts
| No | Part | Material |
| 1 | Cap | ASTM A351 CF8, CF8M |
| 2 | Sea | PTFE, RPTFE, PPL |
| 3 | Ball | SS 304,SS 316 |
| 4 | Seal Ring | PTFE |
| 5 | Body | ASTM A351 CF8, CF8M |
| 6 | Gasket | PTFE, RPTFE |
| 7 | Packing | PTFE, RPTFE, PPL |
| 8 | Stem | SS 304, SS 316 |
| 9 | Gland | SS 304 |
| 10 | Handle | SS 201 |
| 11 | Nut | A194-8 |
| 12 | Gasket | SS 304 |
| 13 | Lock Sheet | SS 201 |
| 14 | Holster | PVC |
Main Dimensions (Inch)
| Size | Port | Pressure | d | L | H | H1 | E |
| 1/2 Inch | FP | 1000 PSI | 15 | 62 | 60 | 27 | 98 |
| 3/4 Inch | FP | 1000 PSI | 20 | 70 | 67 | 30.5 | 120 |
| 1 Inch | FP | 1000 PSI | 25 | 81 | 70 | 33.5 | 120 |
| 1-1/4 Inch | FP | 1000 PSI | 32 | 96 | 82 | 42 | 150 |
| 1-1/2 Inch | FP | 1000 PSI | 38 | 105 | 91 | 46.5 | 170 |
| 2 Inch | FP | 1000 PSI | 48 | 120 | 100 | 56.5 | 170 |
| 2-1/2 Inch | FP | 1000 PSI | 65 | 138 | 125 | 72.5 | 250 |
| 3 Inch | FP | 1000 PSI | 78 | 170 | 142 | 89 | 250 |
| 4 Inch | FP | 1000 PSI | 100 | 205 | 163 | 102.5 | 300 |
