Orbit Rising Stem Ball Valve, API 6D, A352 LCC, 8 IN, CL300
- Product Name:
- Orbit Rising Stem Ball Valve
- Design Standard:
- API 6D
- Body Material:
- ASTM A352 LCC
- Size:
- 8 Inch, DN200
- Pressure:
- Class 300 LB, PN50
- End Connection:
- RF Flanged
- Operation:
- Bevel Gear
- Temperature Range:
- -29°C to 425°C
- Medium:
- Water, Oil, Gas, etc
Key Specifications / Features
The Orbit Rising Stem Ball Valve Factory produces high-quality ball valves designed to meet API 6D standards. These valves are made from ASTM A352 LCC low-temperature carbon steel, ensuring durability and reliability in demanding applications. With an 8-inch (DN200) diameter and rated at Class 300 LB and PN50 pressure classes, they feature raised face (RF) flanged ends for secure connections. The valves are operated using a bevel gear mechanism, providing smooth and precise control.
Orbit Rising Stem Ball Valves are engineered for reliable shut-off service in critical applications such as oil and petroleum products, natural gas, and chemical pipelines and stations. These valves feature a unique rising stem mechanism in which the ball rotates around the body's centerline to open or close, ensuring smooth, frictionless switching. The valve's single-seat design, combined with low torque requirements and a wedge-seal structure, provides tight and dependable sealing that remains unaffected by pipeline pressure differentials. Additionally, the self-cleaning action of the sealing surfaces enhances long-term durability and service life, even under challenging operating conditions.
Technical Specifications
» Type: Orbit Rising Stem Ball Valve
» Size Range: NPS 2-28 Inch (DN50-DN700)
» Design Pressure: ASME Class 150-1500 LB (PN10-PN250)
» Body Materials: Cast Carbon Steel, Stainless Steel, Duplex, and Special Alloys
» Ball Material: Nickel-based alloy spray welded sealing surface
» Seat Material: Nickel-based alloy spray welded sealing surface
» Stem Materials: XM-19, 17-4PH, and others
» End Connections: Flanged RF, RTJ, Butt Weld (BW)
» Operation Methods: Handwheel, Bevel Gear, Electric, Pneumatic
Design Standards
» Design & Manufacture: API 6D, ASME B16.34
» Face-to-Face/End-to-End: ASME B16.10
» Flanged Connections: ASME B16.5, ASME B16.47
» Butt Welded Ends: ASME B16.25
» Testing & Inspection: API 598, API 6D
» Fire Safety Compliance: API 607, API 6A
Product Features
» One-piece body construction
» In-line maintenance capability
» Low operating torque
» Emergency sealing provision
» Reliable and consistent sealing
» Double Block & Bleed (DBB) functionality
» Anti-static and fire-safe design
» Optional extended stem
» Multiple actuation options available
