Industrial Forged Steel Ball Valve Floating Type With Thread Connection Form
- Application:
- Industrial Usage, Water Industrial Usage, Household Usage
- Materials:
- Carbon Steel
- Function:
- Blow-Down Valve
- High Light:
- float operated ball valve , 3 piece floating ball valve
- Structure:
- Floating Ball Valve
- Standard:
- BS5351
- Media:
- Oil
- Connection Form:
- Thread
- Nominal Pressure:
- ANSI CLASS 150-900
- Temperature:
- Normal Temperature
- Driving Mode:
- Manual
- Channel:
- Straight Through Type
- Body / Ball / Stem / Seat:
- A105, SS304, SS304L, SS316, SS316L, Ss347, 904L
3 PCS Forged Floating Ball Valve
JIEYU Valve manufactures some of the most dependable cast and forged steel Ball Valves in the industry. Our products are manufactured and tested in accordance with respective API, ASME, and ANSI standards. With features such as double block and bleed capabilities, secondary sealant injections, and spring energized self relieving seats, the JIEYU design offers many features and options beneficial for oil, gas, and liquid applications making it one of the most preferred ball valves on the market.
Size range(s): NPS 1/2 - 2 (DN 15 - 50)
Pressure rating: ASME Classes 150 - 2500
Standard connections: Threaded, socket weld, flanged
Material Selection for Gate Valves:
- Carbon Steel (A105)
- Low Temperture Carbon Steel (LF2)
- Stainless Steel (SS304, SS304L, SS316, SS316L, SS347, 904L)
- Low Alloys (F1, F11, F22)
- High Alloys (F5, F9,F91, F62, F20 )
- Duplex & Super Duplex (2205, 2507, S32760)
- Bronze (C95800, C95500, C95400)
- Inconel (Inconel 625, Inconel 825)
