Full Bore Carbon Steel Gate Valve Russian Standard Environmentally Friendly
- Certification:
- API ISO Ts CE
- Minimum Order Quantity:
- 1PC
- Prices:
- Negotiable
- Packaging Details:
- Plywood Case
- Delivery Time:
- 7-30 work days
- Payment Terms:
- L/C, D/A, D/P, T/T, Western Union, MoneyGram
- Supply Ability:
- 10000PCS/Mouth
Detailed Product Description
| Media: | Gas | Temperature: | Low Temperature |
|---|---|---|---|
| Type: | Direct-acting | Material: | Carbon Steel |
| Connection Form: | Flange | Pressure: | Ordinary Temperature |
| Actuator: | Manual | Seal Surface: | Wedge Gate Valve |
| Thread Position Of Valve Rod: | Outside Gate Valve | Usage: | Regulation |
| Standard: | GOST | Application: | Industrial Usage, Water Industrial Usage, Household Usage |
| High Light: | industrial gate valve , full bore gate valve | ||
Russian Standard Gate Valve
Specification:
Size: DN15-DN1200
Model:Z40H
Pressure: PN16-PN250
Material: 1.0619/GP240GH/GS-C25(WCB), 1.7357 (WC6) ,1.7379/1.7382(WC9),1.7363 (C5), 1.7389 (C12), 1.4308(CF8), 1.4408(CF8M), 1.4552(CF8C).Etc
Type: Rising Stem and Wedge Single Disc, Solid or Flexible wedge, flat gate.
Operation: Handwheel, gear worm ,Electric operated
Standard:
Design & Manufacture Std.: GB/T12234,DIN3352,GOST 12820-80,Etc.
Face to Face Std.: GB/T12221,DIN3202,Etc.
End Connection Std.: JB/T79,DIN2543-2550,GOST 12820-80,Etc.
Test Standard: ISO5208, API 600, BS 6755
| NO. | Part Name | Material | |
| 01 | Body | ASTM A216WCB | GS-C25,CF8,CF8M |
| 02 | Seat Ring | ASTM A216+13Cr | |
| 03 | Wedge | ASTM A216+13Cr | |
| 04 | Stem | ASTM A276 420 | 13Cr.F304,F316 |
| 05 | Gasket | 304+Graphite | GS-C25,CF8,CF8M |
| 06 | Bonnet | ASTM A216WCB | |
| 07 | Stud | ASTM A193 B7 | ASTM A193-B8 |
| 08 | Nut | ASTM A194 2H | ASTM A194-8 |
| 09 | Backseat | ASTM A216+13Cr | |
| 10 | Stud | ASTM A193 B7 | |
| 11 | Nut | ASTM A194 2H | |
| 12 | Yoke | ASTM A216WCB | |
| 13 | Packing | Graphite | |
| 14 | Pin | ASTM A276 410 | C.S SS304 SS316 |
| 15 | Gland Bolt | ASTM A193 B7 | |
| 16 | Gland Nut | ASTM A194 2H | |
| 17 | Bushing | ASTM A276 410 | |
| 18 | Gland | ASTM A216WCB | |
| 19 | Bearing | ASTM A29 | A105,F304,F316 |
| 20 | Stem Nut | ZcuAl10Fe3 Bronze | Bronze,SS304,SS316 |
| 21 | Lubricator | Cu | Brass |
| 22 | Retaining Nut | C.S | |
| 23 | Handwheel | ASTM A47 | A105,F304,F316 |
| 24 | H.W. Lock Nut | C.S | 25#,SS304,SS316 |
