Electric - Actuated Cast Steel Gate Valve 1/2" - 8" Pressure 150lb - 1500lb
- Size:
- 1/2"-8"
- Pressure:
- 150lb-1500lb
- Operation:
- Handwheel
- Materials:
- ASTM A 216 WCB / A 217 WC6 / A 217 WC9 / A 217 C5 / A 217 C12 / A 351 CF8 / A 351 CF8M / A 351 CF3 / A 351 CF3M / A 352 LCB
- High Light:
- flanged gate valve , industrial gate valve
- Media:
- Oil, Gas, Water, Steam, Acids
- Connection End Type:
- Bolted Bonnet Socket-Welding End, Threaded End, Flange End, Socket-Welding & Threaded End (to Order)
Electric - Actuated Cast Steel Gate Valve 1/2" - 8" Pressure 150lb - 1500lb
Design Description
Full Port Design
OS&Y, outside screw and yoke
BB, Bolted Bonnet
Flexible wedge, fully guided
Choice of Solid or Split Wedge
Renewable Seat Rings
Rising Stem and Non-rising Handwheel
Flanged
Available with BG operator.
Standard:
Steel Gate Valves, API 600/API 6D
Steel Gate Valves, ISO 10434/ISO14313
Steel Valves, ASME B 16.34
Face to Face: ASME B16.10
End Flanges: ASME B16.5
Inspection and Test, API 598 /API 6D
Specification
| Product Name | API Wcb Flange Cast Steel Gate Valve (150LB~1500LB) |
| 1. Material | A351 CF8M/CF8/CF3/CF3M, A216 WCB |
| 2. Size | 1 1/2''~48'' ( DN40~DN1200) |
| 3.Certificate | ISO9001 & CE |
| 4. Port | Full Port |
| 5. Working Pressure | 150LB~1500LB |
| 6. Connection Ends | Flange |
| 7. Working Temp. | -196ºC~450ºC |
| 8. Suitable Medium | Water, Natural Gas, Oil and some corrosive liquid |
| 9. Seal | Metal |
| Standard | |
| Design & Manufacture standard: | API 600, API 6D |
| Pressure & Temperature standard: | ASME B16.34 |
| Face to Face | ASME B16.10 |
| Flange Dimension | ASME B16.5 |
| Inspection & Testing | API598 |
| Shipment | |
| Delivery Time | 15~20 Days |
| Package | Standard Exporting Plywood Case |
| Shipping Port | Ningbo/Shanghai, China |
| Shipping Terms | Exw, FOB, CFR, CIF, etc. |
| Payment Terms | T/T, Western Union, PayPal, etc. |
| 30% prepayment, 70% balance paid before shipping or against copy of BL | |
| Warranty | 12 Months after leaving factory |
| Others | We also manufacture Flange Ball Valve, Gate Valve, Globe Valve, Check Valve, Butterfly Valve & Y Strainer |
