Lever Operation Industrial Globe Valve Flange Type , Carbon Steel Globe Valve

Large Image : Lever Operation Industrial Globe Valve Flange Type , Carbon Steel Globe Valve

Product Details:

Place of Origin:	Wenzhou China
Brand Name:	JIEYU
Certification:	API ISO Ts CE

Payment & Shipping Terms:

Minimum Order Quantity:	1PC
Price:	Negotiable
Packaging Details:	Plywood Case
Delivery Time:	7-30 work days
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability:	10000PCS/Mouth

Contact Now

Detailed Product Description

Size:	1/2"~36"	Operation:	Lever
Material:	Carbon Steel	Flanged Dimenson:	ASME B16.5, ASME B16.47, BSEN 1092
Connection End Type:	ASME B16.25BSEN 558, ASME B16.5 ,BSEN 1092	Pressure:	CL150~2500
High Light:	flange globe valve , industrial globe valve

Flanged End Cast Globe Valve Carbon Steel 1/2" - 36" Size Stainless Steel Material

Specifications:

1/2"~36"(DN15~DN900)
W. P.:PN16 CLASS 150/300/600/900/1500/2500

ITEM	PARTS	MATERIAL
ITEM	PARTS	Trim1	Trim5	Trim8
1	BODY	ASTM A216-WCB
2	SEAT RING	ASTM A216-WCB+Cr13	ASTM A105+STL#6	ASTM A105+STL#6
3	DISC	ASTM A216-WCB+Cr13	ASTM A105+STL#6	ASTM A216-WCB+Cr13
4	STEM	ASTM A182-F6a
5	GASKET	SPW SS304+GRAPHITE
6	BONNET	ASTM A216-WCB
7	NUT	ASTM A194-2H
8	STUD	ASTM A193-B7
9	BACK SEAT	ASTM A276-410
10	PACKING A	GRAPHITE
11	PACKING B
12	PACKING C
13	GLAND	ASTM A276-410
14	GLAND FLANGE	ASTM A216-WCB
15	STEM BUSHING	ASTM A439 D-2
16	SCREW	ASTM A29-1035
17	HANDWHEEL	DUCTILE IRON
18	WASHER	ASTM A29-1025
19	HANDWHEEL NUT	ASTM A29-1045
20	DISC NUT	ASTM A276-410
21	EYE BOLT	ASTM A193-B7
22	NUT	ASTM A194-2H
23	PIN	ASTM A29-1025
24	NAMEPLATE	SS 304
25	RIVET	SS 304

Tag:

wcb globe valve,

industrial globe valve,

flange globe valve
